Vehicle battery charger 30/15 A
Motor vehicle battery charger 30/15 A
CHRG-BTRY-VEH-12/24V-30/15AMP-XL-LED
Register now and access more than 125,000 products
Combines 12-V and 24-V applications in a single device
The integrated temperature sensor at the charging terminals ensures that the battery is charged in a controlled and gentle manner.
Protected in accordance with IP30
Features a 30-A supply mode
that keeps the battery fully charged even during maintenance and diagnostics work.
Due to its compact design, this charger is also ideal for use in showrooms
Standard charging
For conventional batteries (wet batteries, open design), maintenance-free batteries, gel and closed batteries
Cold charging function
Used when the battery temperature is lower than 5°C and for AGM GEL batteries
Boost function
Intensive mode for deeply discharged batteries
Supply mode
Used as a power supply in the showroom or during maintenance work
Integrated battery tester
4-stage LED display
Multifunctional holding device
Various operating positions are possible thanks to the integrated holding device (standing, hand-held, hanging and wall-mounted — all possible with the same holding device)
Please note that the spark protection feature will not function in supply mode.
RoHS, REACH, EMV, CE
Datasheets(X)
Recommended for battery capacities between 90 and 600 Ah.
Test (Display: "Battery full" LED flashes)
This mode checks the vehicle battery for damage.
Gentle charging (Display: "Discharged" LED flashes)
This mode is selected for deeply discharged vehicle batteries. In this mode, the vehicle battery is prepared for "normal charging".
Desulphurisation (Display: "Low" LED flashes)
This mode is selected following a longer break in operation of the vehicle battery to desulphurise it by means of pulse charges.
Normal charging/intensive charging (Display: "Low" LED flashes)
This mode charges the vehicle battery via a continuous flow of current until the battery is charged to 85% of its capacity.
Absorption (Display: "Battery full" LED flashes)
This mode charges the vehicle battery at a constant voltage (normal charging: 14.0 V/cold charging: 14.4 V) until the battery is charged to 98% of its capacity.
Recharging (Display: "Battery full" LED flashes)
In this mode, the remaining 2% of capacity before the battery is fully charged is charged at a higher voltage (normal charging: 14.4 V/cold charging: 14.8 V) and a lower current to protect the vehicle battery.
Test (Display: "Battery full" LED flashes)
If the voltage of the vehicle battery drops to 11.6 V within ten minutes, the battery is considered defective and must be replaced.
Maintenance (Display: "Battery full" LED is constantly illuminated)
This mode conducts continuous voltage measurements at 12.6 and 25.2 V. If the voltage drops, the charging process is restarted.
Intensive mode (Display: "Discharged" LED flashes)
This mode is used for rapid charging and for deeply discharged vehicle batteries. The vehicle battery is intensively charged at the maximum current for 30 minutes and then tested to ensure that it is possible to proceed with normal charging. If the battery voltage is still insufficient, intensive charging is continued. This process is repeated a maximum of four times. If this is not sufficient to charge the battery, the charger displays an error.
Frequency | 50 Hz |
Min. charging voltage | 12 V/AC |
Max. charging voltage | 24 V/AC |
Min./max. rechargeable battery/battery capacity | 90-600 Ah |
Battery designation | 12 V lead-acid batteries (open, MF, calcium, VRLA, GEL, AGM fleece) |
Charging characteristics | 7-step fully automatic charging characteristic |
IP protection class | IP 30 |
Cable length | 1800 mm |
Fully insulated charging terminals | Yes |
Cable cross section | 4 mm² |
Length x width x height | 230 x 118 x 70 mm |
Product weight (per item) | 1920.000 g |
Included in delivery | Fully insulated charge clamps with integrated temperature sensor |
Spark protection | Yes |
Reverse-polarity protection | Yes |
